Description
GALAX RTX 5080 1-Click OC (Black) – 16 GB GDDR7, 256-bit graphics card:
Specifications & Features
🔹Official Specs (GALAX)
-
Memory: 16 GB GDDR7 on a 256-bit bus with up to 960 GB/s memory bandwidth (30 Gbps × 256-bit)
-
GPU Architecture: NVIDIA Blackwell, featuring 10,752 CUDA cores .
-
Clock Speeds:
-
Base/Boost Clock: 2.30 GHz / 2.62 GHz (2625 MHz)
-
1-Click OC via GALAX’s Xtreme Tuner Plus: ~2640 MHz
-
Connectivity: 3 × DisplayPort 2.1b, 1 × HDMI 2.1b .
-
Cooling: Triple-fan (3 × 92 mm) WINGS 3.0 with fan-stop at idle .
-
Form Factor: 315 × 140.5 × 50.7 mm (with bracket), 303 × 125 × 49.7 mm (without bracket) – SFF-ready.
-
Power & TDP: Rated around 360 W, requires high-watt PSU (850 W recommended by NVIDIA)
-
Powered by the NVIDIA Blackwell Architecture and DLSS 4
-
Dedicated Tensor Cores
-
Dedicated RT Cores
-
Microsoft DirectX® 12 Ultimate
🔹Summary
| Feature | GALAX RTX 5080 1-Click OC (Black) |
|---|---|
| Memory | 16 GB GDDR7, 256-bit, 960 GB/s |
| CUDA Cores | 10,752 |
| Boost Clock | 2.625 GHz (2.64 GHz with 1-Click OC) |
| Cooling | Triple-fan, fan-stop idle |
| Size | 315 × 140.5 × 50.7 mm (bracket) |
| Power Consumption | 360 W (850 W PSU recommended) |
| Brand | GALAX |
